    90° Curved 5 - Step NDT Calibration Blocks Pipe Thikness Test Block Calibration Certificate

    Ask Lasest Price
    Brand Name : HUATEC
    Model Number : 90° Curved 5-Step Block
    Certification : CE, Calibration Certificate
    Payment Terms : TT, L/C, Western Union
    Supply Ability : 1000pcs per month
    Delivery Time : 3-7 working days,V1 and V2 have stock
    • Product Details
    • Company Profile

    90° Curved 5 - Step NDT Calibration Blocks Pipe Thikness Test Block Calibration Certificate

    Ultrasonic Calibration Block 90° Curved 5-Step Block for thickness and linearity calibration of curved surface


    Specifications:
    Calibration blocks is an important supplementary material in the Ultrasonic testing, used to calibrate the sensitivity of the ultrasonic flaw detector and ultrasonic probe. Our testing block is certificated by the authority of the state depeartment. Our products include: domestic standards UT blocks, European standard UT block, NDT block, hexagonal testing block, and so on. Processing of the special specifications UT block

    For thickness and linearity calibration of curved surfaces. This 90° Curved 5-Step block is machined from solid 2" diameter bar with step thicknesses of .100", .200", .300", .400" and .500". ID radius is a constant 0.50" / 1.00" diameter.


    P/N

    Description

    Step Thickness

    1

    5SP-CS

    5 Step Pipe Step Wedge,Carbon Steel

    0.10”, 0.20”, 0.30”, 0.40”, 0.50”

    2

    5SP-SS

    5 Step Pipe Step Wedge, S Steel 304

    0.10”, 0.20”, 0.30”, 0.40”, 0.50”


    Block Curvature:
    • 0.500” step is a 1.0” radius
    • 0.400” step is a 0.9” radius
    • 0.300” step is a 0.8” radius
    • 0.200” step is a 0.7” radius
    • 0.100” step is a 0.6” radius

    Step face is 1.000" x 90° arc.


    1018 carbon steel, LY12/6063/7075 aluminum,304 Duplex stainless steel optional90° Curved 5 - Step NDT Calibration Blocks Pipe Thikness Test Block Calibration Certificate

    90° Curved 5 - Step NDT Calibration Blocks Pipe Thikness Test Block Calibration Certificate

    Quality 90° Curved 5 - Step NDT Calibration Blocks Pipe Thikness Test Block Calibration Certificate for sale
